Mast Chain

Forklift Mast Chains - Leaf Chains consist of various functions and are regulated by ANSI. They are meant for tension linkage, forklift masts and for low-speed pulling, and as balancers between head and counterweight in some machine gadgets. Leaf chains are occasionally likewise called Balance Chains.

Features and Construction

Made of a simple pin construction and link plate, steel leaf chains is identified by a number which refers to the pitch and the lacing of the links. The chains have specific features like high tensile strength for each section area, which allows the design of smaller machines. There are B- and A+ kind chains in this series and both the AL6 and BL6 Series have the same pitch as RS60. Lastly, these chains cannot be powered utilizing sprockets.

Selection and Handling

Comparably, in roller chains, all of the link plates maintain higher fatigue resistance due to the compressive stress of press fits, whereas in leaf chains, only two outer plates are press fit. The tensile strength of leaf chains is high and the maximum acceptable tension is low. If handling leaf chains it is vital to check with the manufacturer's instruction booklet in order to ensure the safety factor is outlined and utilize safety measures all the time. It is a good idea to exercise extreme caution and utilize extra safety guards in functions where the consequences of chain failure are severe.

Utilizing more plates in the lacing results in the higher tensile strength. As this does not improve the maximum allowable tension directly, the number of plates used can be limited. The chains need frequent lubrication because the pins link directly on the plates, producing a very high bearing pressure. Utilizing a SAE 30 or 40 machine oil is normally advised for most applications. If the chain is cycled over 1000 times daily or if the chain speed is over 30m for each minute, it would wear extremely fast, even with continual lubrication. So, in either of these situations utilizing RS Roller Chains will be a lot more suitable.

AL type chains are only to be utilized under certain conditions like where there are no shock loads or when wear is not a big issue. Make positive that the number of cycles does not exceed one hundred every day. The BL-type will be better suited under other situations.

The stress load in components would become higher if a chain using a lower safety factor is selected. If the chain is likewise used among corrosive situations, it can easily fatigue and break very fast. Doing regular maintenance is really important if operating under these types of conditions.

The inner link or outer link type of end link on the chain would determine the shape of the clevis. Clevis connectors or also known as Clevis pins are made by manufacturers, but the user normally provides the clevis. An improperly constructed clevis could reduce the working life of the chain. The strands must be finished to length by the maker. Check the ANSI standard or get in touch with the manufacturer.
